Panasonic MINAS A5 MHMJ042S1S Servo Motor 200V 400W
Product Description
Product Description
Panasonic MINAS A5 MHMJ042S1S Servo Motor 200V 400W
The Panasonic MINAS A5 MHMJ042S1S Servo Motor represents the pinnacle of precision and reliability in motion control technology. Designed for advanced automation and industrial applications, this high-performance servo motor delivers exceptional torque, speed, and efficiency.
Key Features:
- Power Rating: 400W, providing robust performance for demanding applications.
- Voltage: Operates at 200V, ensuring compatibility with a wide range of industrial power systems.
- High-Resolution Encoder: Integrated high-resolution encoder for precise feedback and accurate positioning.
- Advanced Control Algorithms: Utilizes Panasonic’s proprietary control algorithms to optimize torque response, reduce vibration, and enhance overall system stability.
- Compact Design: Engineered with a compact form factor that allows for installation in space-constrained environments without compromising on performance.
- Robust Construction: Built to withstand harsh industrial conditions, featuring a durable housing and high-quality materials for long-lasting operation.
- Low Noise Operation: Designed to minimize operational noise, contributing to a quieter working environment.
- Enhanced Cooling: Equipped with an efficient cooling system to maintain optimal motor temperature and performance under continuous load conditions.
- Compatibility: Ideal for integration with Panasonic MINAS A5 servo drives and other compatible motion control systems.
Applications:
The MINAS A5 MHMJ042S1S is ideal for a wide range of applications including robotics, CNC machinery, conveyor systems, and other automated equipment where high precision and reliability are crucial. Its superior performance makes it a preferred choice for engineers and system integrators seeking to enhance their automation solutions.
Technical Specifications:
- Rated Power: 400W
- Rated Voltage: 200V
- Rated Current: 2.1A
- Max Speed: 3000 RPM
- Encoder Resolution: 20-bit
- Protection Class: IP65
- Operating Temperature Range: -10°C to +40°C
Benefits:
- Precision Engineering: Provides high precision and repeatability to ensure consistent quality in automated processes.
- Increased Efficiency: Advanced algorithms and high-resolution feedback contribute to reduced energy consumption and improved overall efficiency.
- Durability: Designed to perform reliably in demanding environments, reducing maintenance needs and extending service life.
Choose the Panasonic MINAS A5 MHMJ042S1S Servo Motor for superior performance, reliability, and precision in your automation projects.
Panasonic MINAS A5 Family MHMJ042S1S Servo Motor 200V 400W
Spec Detail
| Item | Specifications |
|---|---|
| Part Number | MHMJ042S1S |
| Details | High inertia, Connector type, IP65 |
| Family Name | MINAS A5 |
| Series | MHMJ Series |
| Type | High inertia |
| Special Order Product | Special Order Product |
| Cautions for Special ordering product | Please avoid the motor, or equipment containing the motor to be distributed to Japan, or other regions through Japan. |
| Enclosure | IP65 |
| About Enclosure | Except rotating portion of output shaft and leadwire end. |
| Environmental Conditions | For more details, please refer to the instruction manual. |
| Flange sq. dimension | 60 mm sq. |
| Flange sq. dimension (Unit:mm) | 60 |
| Motor lead-out configuration | Connector |
| Motor encoder connector | Connector |
| Power supply capacity (kVA) | 0.9 |
| Voltage specifications | 200 V |
| Rated output | 400 W |
| Rated current (A (rms)) | 2.6 |
| Holding brake | without |
| Mass (kg) | 1.4 |
| Oil seal | without |
| Shaft | Key-way, center tap |
| Rated torque (N ⋅ m) | 1.3 |
| Momentary Max. peak torque (N ⋅ m) | 3.8 |
| Max. current (A (o-p)) | 11.0 |
| Regenerative brake frequency (times/min) | Without option :No limit With option :No limit Option (External regenerative resistor) Part No. : DV0P4283 |
| About regenerative brake frequency | Please refer to the details of [Motor Specification Description] , Note: 1, and 2. |
| Rated rotational speed (r/min) | 3000 |
| Rated rotational Max. speed (r/min) | 5000 |
| Moment of inertia of rotor ( x10-4 kg ⋅ m²) | 0.67 |
| Recommended moment of inertia ratio of the load and the rotor | 30 times or less |
| About recommended moment of inertia ratio of the load and the rotor | Please refer to the details of [Motor Specification Description] ,Note: 3. |
| Rotary encoder: specifications | 17-bit Absolute/Incremental system |
| Notice | When using a rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder. |
| Rotary encoder: Resolution | 131072 |
Permissible load
| Item | Specifications |
|---|---|
| During assembly: Radial load P-direction (N) | 392 |
| During assembly: Thrust load A-direction (N) | 147 |
| During assembly: Thrust load B-direction (N) | 196 |
| During operation: Radial load P-direction (N) | 245 |
| During operation: Thrust load A, B-direction (N) | 98 |
| About permissible load | For details, refer to the [Motor Specification Description] "Permissible Load at Output Shaft". |
